Description
Azdome M580 video recorder
Ensure greater safety on the road. The Azdome M580 video recorder consists of a front camera that supports up to 5K resolution, as well as a rear camera and an internal camera. It has built-in GPS and G-sensor, and it also allows loop recording and supports time-lapse mode. It provides excellent image quality, and with 5G Wi-Fi connectivity, it allows you to quickly download and share recorded footage. It also comes with a 64GB memory card.
Premium image
The M580's front camera allows you to record in 5K UHD (when operating independently). This allows you to capture even the smallest detail with ease! On the other hand, if you use all the included devices, the front camera will film in 4K UHD, while the rear and internal camera will film in 1080p FHD. In addition, IR LED backlighting ensures clear images even at night. Enjoy great video quality and don't worry about missing a detail!
Be prepared for any situation
In the event of a traffic collision or a parking lot bump, the Azdome M580 will provide you with the necessary recordings and evidence. The video recorder is equipped with an advanced G-sensor, which detects sudden movements of the vehicle and allows you to automatically record a short video of the incident.
Even more capabilities
The Azdome M580 will serve you in almost any conditions. The video recorder is equipped with a super-capacitor, so it can easily work even in very low (down to -20°) and very high temperatures (up to 70°C). The camera also offers quite a few additional features, such as speed control, screen saver and reminders, for example.
Effortless saving of footage
With the M580, you can rest assured that no important video footage will be lost. The video recorder supports loop recording, which means that when the memory card fills up, the oldest recordings will be automatically overwritten. In addition, you can mark clips to be protected from deletion. Planning a long trip? Turn on Time-lapse mode, which records at 1 FPS to create one long video. This will allow you to record many more events on the road!
Additional features
With 5G/2.4G Wi-Fi support, the M580 video recorder offers fast downloading and sharing of recorded footage. What's more, the built-in GPS module allows you to record information such as route and speed. The device also works with the AZDOME app, which allows you to conveniently manage settings, edit recordings and share them with friends.
Safety in the parking lot
The M580 video recorder can also provide 24-hour monitoring of your car while parked, enabling continuous time-lapse recording and automatic collision detection. This means that even if you have an accident, you will gain essential evidence that will be useful when claiming compensation. Note: an additional wiring kit is required to use this feature, which must be purchased separately.
Included
- Front camera
- Rear camera
- Inner camera
- Cable for rear camera and internal camera
- Electrostatic film x6
- USB-C power cable (3.5m)
- Car charger
- 64 GB memory card
- Cable clamp x5
- Undermining tool
- User manual
| Manufacturer |
Azdome |
| Model |
M580 |
Screen and display
| Screen size |
4 inches |
| Screen type |
IPS |
| Screen resolution |
400x960p |
|
Lens and optics
| Type of lens |
2G5P + 1IR |
| Aperture |
F/NO = 2.0 |
| Focal length |
f = 2.9 mm |
| Viewing angle |
150° |
|
Sensor and image quality
| Sensor |
IMX415 + GC2053 + GC2053 |
| Video resolution |
1 channel: 5K / 5160x2160p 25FPS; 2 channels: 4K / 2160p 30FPS + 1080p 30FPS; 3 channels: 4K / 2160p 25FPS + 1080p 25FPS + 1080p 25FPS; |
| Video format |
MP4 |
| Codecs |
H.264, H.265 |
| Image resolution |
1080p |
| Photo format |
JPG |
Recording functions and data storage
| USB memory |
Yes |
| Supported memory cards |
Yes |
| Max capacity of TF memory card |
256 GB |
| Loop recording |
Yes |
| Monitoring during parking |
Yes |
| Time-lapse |
None |
Connectivity and interfaces
| USB webcam |
None |
| HDMI |
None |
| AV In |
None |
| Wi-Fi |
2.4G + 5G |
| GPS |
Yes |
| Automatic time setting |
None |
| Application |
AZDOME |
Safety and driving assistant
| Motion detection |
None |
| G-sensor |
Yes |
| WDR |
Yes |
| ADAS |
Yes |
| POI (speed alert) |
None |
|
Controls and additional features
| Voice control |
None |
| Taking pictures during video recording |
Yes |
| Locking/unlocking files during video recording |
Yes |
| Setting vehicle number |
Yes |
|
Sound and signaling
| Microphone |
Yes |
| Speaker |
Yes |
| LED indicator |
Yes |
|
Power supply and battery
| Input current |
5 V 2.5 A (USB-C) |
| Power supply |
Power cable |
| Rechargeable battery |
None |
| Battery capacity |
None |
| Charging |
None |
|
Operating conditions and dimensions
| Operating temperature |
From -10°C to 70°C |
| Storage temperature |
From -20°C to 80°C |
| Dimensions |
None |
| Weight |
None |
|
