Cooler Master MWE BRONZE V2 230V 550W Power Supply Unit
- Ships today! The product is in stock at our warehouse located in Finland. Orders are shipped at lightning speed usually the same or next business day. Delivery time depends of the destination country.
- Ships in 4–7 days The product is shipped from supplier warehouse and delivered first to our warehouse located in Finland. You will receive a tracking link by email once we have shipped your order from our warehouse, usually within 4–7 business days after your order.
- Out of stock The product is currently unavailable. Please send a message to our customer service for more information.
Please take a look of our Shipping methods and costs page for more information.
Do you have any question?
We prefer that you send your message with our live chat. Contacting us with the chat allows us to see the product & page where you at the moment so it will be faster for us to check the product you are interested.
We can help you immediately if we are available, if we are busy packing orders we will get back to you and contact you by email & live chat.
If you are in a hurry you can leave your message with the contact form.
Would you like to place a larger wholesale order? Or would like to request for quotation for custom order?
Request for quatation:
- Add all the items and quantities into the cart
- Go to the "Cart page" by clicking this link or click the "Contact us" button in the slider cart.
- In the "Cart page" you can click the "Contact us" button and you can send a message and quote request for your cart items.
Description
Product information
Cooler Master MWE BRONZE V2 230V 550W power supply unit.
The Cooler Master MWE Bronze V2 550W power supply is a solid solution for users looking for performance, reliability and quiet operation at an affordable price. The unit meets the ATX 2.52 standard and offers active PFC, which translates into stable voltages and higher energy efficiency. The whole unit is enclosed in a compact case with flat cables for easy installation and organization inside the case.
Proven performance with 80 PLUS Bronze certification
The MWE Bronze V2 provides an efficiency of 88% at typical load, as certified by 80 PLUS Bronze (EU 230V). Thanks to DC-to-DC technology and a single +12V line, the power supply offers stable voltages for all connected components, which contributes to safe and efficient system operation.
Quiet operation thanks to the HDB fan
The used 120 mm HDB (Hydro Dynamic Bearing) fan automatically adjusts its speed according to the temperature, ensuring optimal cooling while maintaining a low noise level - only 13.8 dBA at 20% load. Even at full load, the noise level does not exceed 32 dBA.
High quality and component protection
The power supply is equipped with a set of protections: OVP, OPP, SCP, UVP and OTP, which protect both the device itself and the entire computer from damage. The average time without failure (MTBF) is more than 100,000 hours, indicating high reliability. The power supply delivers 550W of power and is equipped with a set of basic connectors: 1× 24-pin ATX, 1× EPS 4+4 pin, 4× PCI-E (6+2), 6× SATA and 3× Molex. This makes it a suitable choice for office, gaming and multimedia computers.
| Manufacturer | Cooler Master |
|---|---|
| Manufacturer code | MPE-5501-ACABW-B |
| ATX version | Intel ATX 12V Ver. 2.52 |
| PFC | Active PFC |
| Input voltage | 200-240V |
| Input current | 5A |
| Input frequency | 50-60Hz |
| Dimensions (L × W × H) | 140 × 150 × 86 mm |
| Fan size | 120 mm |
| Bearing type | HDB (hydrodynamic) |
| Fan speed | 1500 rpm |
| Noise level at 20% load | 13.8 dBA |
| Noise level at 50% load | 18.4 dBA |
| Noise level at 100% load | 31.2 dBA |
| Efficiency | 88% at typical load |
| 80 PLUS certification | 80 PLUS Bronze EU 230V |
| ErP 2014 Lot 3 compliance | Yes |
| Power Good signal | 100 - 500 ms |
| Hold-up time | ≥16 ms at full load and 230V |
| MTBF (mean time without failure) | >100,000 hours |
| Security | OVP / OPP / SCP / UVP / OTP |
| Certifications and standards | CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB |
Warranty: 24 months
Cooler Master MWE BRONZE V2 230V 550W power supply unit.
The Cooler Master MWE Bronze V2 550W power supply is a solid solution for users looking for performance, reliability and quiet operation at an affordable price. The unit meets the ATX 2.52 standard and offers active PFC, which translates into stable voltages and higher energy efficiency. The whole unit is enclosed in a compact case with flat cables for easy installation and organization inside the case.
Proven performance with 80 PLUS Bronze certification
The MWE Bronze V2 provides an efficiency of 88% at typical load, as certified by 80 PLUS Bronze (EU 230V). Thanks to DC-to-DC technology and a single +12V line, the power supply offers stable voltages for all connected components, which contributes to safe and efficient system operation.
Quiet operation thanks to the HDB fan
The used 120 mm HDB (Hydro Dynamic Bearing) fan automatically adjusts its speed according to the temperature, ensuring optimal cooling while maintaining a low noise level - only 13.8 dBA at 20% load. Even at full load, the noise level does not exceed 32 dBA.
High quality and component protection
The power supply is equipped with a set of protections: OVP, OPP, SCP, UVP and OTP, which protect both the device itself and the entire computer from damage. The average time without failure (MTBF) is more than 100,000 hours, indicating high reliability. The power supply delivers 550W of power and is equipped with a set of basic connectors: 1× 24-pin ATX, 1× EPS 4+4 pin, 4× PCI-E (6+2), 6× SATA and 3× Molex. This makes it a suitable choice for office, gaming and multimedia computers.
| Manufacturer | Cooler Master |
|---|---|
| Manufacturer code | MPE-5501-ACABW-B |
| ATX version | Intel ATX 12V Ver. 2.52 |
| PFC | Active PFC |
| Input voltage | 200-240V |
| Input current | 5A |
| Input frequency | 50-60Hz |
| Dimensions (L × W × H) | 140 × 150 × 86 mm |
| Fan size | 120 mm |
| Bearing type | HDB (hydrodynamic) |
| Fan speed | 1500 rpm |
| Noise level at 20% load | 13.8 dBA |
| Noise level at 50% load | 18.4 dBA |
| Noise level at 100% load | 31.2 dBA |
| Efficiency | 88% at typical load |
| 80 PLUS certification | 80 PLUS Bronze EU 230V |
| ErP 2014 Lot 3 compliance | Yes |
| Power Good signal | 100 - 500 ms |
| Hold-up time | ≥16 ms at full load and 230V |
| MTBF (mean time without failure) | >100,000 hours |
| Security | OVP / OPP / SCP / UVP / OTP |
| Certifications and standards | CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB |
Warranty: 24 months
